Intervalve’s GKL series valves are designed to meet the demanding requirements of the general utility valve market with the HVAC segment in particular. IVGKL is a truly fit & forget valve, which requires minimal maintenance.

The body liner which also functions as the soft seat, comes in an integrally molded (bonded) version and offers 100% bi-directional sealing. The wafer style body has universal design to fit between pipe flanges of almost all popular flange standards.

A real workhorse from the IV stables, IVGK model Butterfly valve incorporates the optimum design features to provide long trouble free service in the field. This general purpose soft seated Butterfly valve has a fully rubber lined single piece body with centric disc construction and is available in wafer type body pattern.

The body liner which also functions as the soft seat, comes in either a replaceable version or an integrally molded (bonded) version and offers 100 % bi-directional sealing against vacuum to rated pressure of PN10 or PN16.

The wafer style body has universal design to fit between pipe flanges of almost all popular flange standards.

Yet another real workhorse from the IV stables, IVTL model Butterfly valve incorporates the optimum design features to provide long trouble free service in the field. This general purpose soft seated Butterfly valve has a fully rubber lined single piece body with a centric disc construction and is available in wafer lugged style body pattern to ensure precise location in pipeline.

The body liner which also functions as the soft seat, come either in a replaceable version or an integrally moulded (bonded) version and offers 100 % bi-directional sealing against full vacuum to rated pressures of PN10 or PN16.

IVTLE model Butterfly valve incorporates the optimum design features to provide long trouble free service in the field. This general purpose soft seated Butterfly valve has a fully rubber lined single piece body with a centric, rubber encapsulated disc construction  and is available in wafer lugged body pattern to ensure precise location in pipe line.

The body liner which also functions as the soft seat, comes integrally moulded (bonded) version and offers 100% bi-directional sealing against rated pressures of PN10.

The lugged version with threaded holes can be used as end of line valves or terminal end valves.

IVGE model Butterfly valve incorporates the optimum design features to provide long trouble free service in the field. This general purpose soft seated Butterfly valve has a fully rubber lined single piece body with a centric, rubber encapsulated disc construction  and is available in wafer lugged body pattern.

The body liner which also functions as the soft seat, comes integrally moulded (bonded) version and offers 100% bi-directional sealing against rated pressures of PN 10. The wafer style body has universal design to fit between pipe flanges of almost all popular flange standards.

Intervalve’s PTFE lined Butterfly valve model IVTFE provides an optimum solution to the corrosion problems encountered by the chemical process industries with conventional Butterfly valves. The PTFE seat liner covers the entire wetted surface of the body and extends on to the flange contact faces, thus eliminating possibility of any media contact with the body metal.

The circularly moulded full  back up elastomer and live loaded disc shoulder sealing ensures bubble tight closing of the Valve with zero shaft leakage. The valve is adaptable for ON / OFF as well as control duty and can be fitted with actuators and accessories as required to meet the specific duty conditions.
